Tufner TUF-MADE MAX Floor Scale

Tufner TUF-MADE MAX Floor Scale

Tufner Tuf-Made-Max is an extra heavy-duty floor scale with structural steel channel frame. 1/4" thick rugged diamond safety tread plate. Sand blasted and powder coated surface for inside or outside use. (4) NTEP certified alloy steel shear beam load cells. 20ft. double armor shielded load cell cable for harsh environments. Side access NEMA type 4X junction box with signal trim card.

RFQ

Call: (919) 776-7737

Tufner TUF-MADE MAX Floor Scale

Tufner Weighing Systems industrial floor scales weigh dependably and accurately, even in tough, demanding environments. Manufactured with durable materials, these platform scales are built to increase productivity. Tufner Inc. scales are available in a wide range of standard and customized configurations to suit your application needs. Tufner scales can be paired with a range of Tufner T-900 series digital weight indicators, software, and accessories for a complete weighing and data management solution.




tufner tuf-made MAX industrial floor scale (underside)



  • Extra heavy-duty pallet scale with structural steel channel frame
  • Low profile design
  • 1/4" thick rugged diamond safety tread plate
  • Sand blasted and powder coated surface for outside use
  • 4 NTEP certified alloy steel shear beam load cells
  • 20ft. double armor shielded load cell cable for harsh environments
  • Side access NEMA type 4X junction box with signal trim card
  • 4 adjustable alloy steel ball joint support feet
  • 4 drilled deck holes, for easy scale height adjustment
  • Capacity is 2X the scale capacity for 200% overload protection
  • Factory pre-calibrated for quick set up





MODEL         PLATFORM SIZE              CAPACITY               SHIP WT.
TMX-544       4’ x 4’ x 3.8” H         5,000 lb x 1 lb / 2,500 kg      408 lbs
TMX-1044     4’ x 4’ x 3.8” H        10,000 lb x 2 lb / 5,000 kg      408 lbs
TMX-555       5’ x 5’ x 3.8” H          5,000 lb x 1 lb / 2,500 kg      545 lbs
TMX-1055     5’ x 5’ x 3.8” H         10,000 lb x 2 lb / 5,000 kg     545 lbs

*OTHER SIZES AVAILABLE. CONTACT US FOR SCALE AND INDICATOR PACKAGE PRICES









Accessories
Access ramps
Pit frame
Bumper guards
Portability frame
Indicator upgrade (Versa, Vigor, Repel)
Label printer
Indicator floor stand
Scoreboard/Remote Display
Data logging software
