For more than 50 years, Thurman Scale has been providing top quality weighing equipment for industries including Agricultural, Mining, Timber, and Steel. Thurman Scale specializes in off-road type vehicle scales. Off road or on, Thurman Scales are built to the highest standards in the industry as a direct result of years of truck weighing experience in demanding workplace environments. Many of these models offer traditional rocker column designs.
Thurman 8565 Falcon Series are fully electronic, low profile truck scales designed for easy installation, while providing accurate and reliable results in heavy duty weighing applications. With its dependable factory-welded, steel deck weighbridge design the 8565 Series truck scales can be quickly installed. Built to last with superior Flintec rocker column load cell design. Available in standard, heavy duty, and extra heavy duty versions.
Stainless Steel, IP69K, hermetically sealed, rocker column load cells.
Deck design distributes load evenly to resist deflection.
Open bottom allows air to circulate, reducing moisture and corrosion.
Legal-for-trade, stainless, steel, dump through modules in custom sizes.
Industrial paint system stands up to truck loads and extreme weather.
All electronics are externally mounted for easy access and fast routine maintenance.
8565 FALCON SERIES SPECIFICATIONS
Platform
Construction . . . . . . . . . . . . . . . . . Steel Deck (Concrete also available)
Widths . . . . . . . . . . . . . . . . . . . . . 10’, 11’, and 12’ standard
Lengths . . . . . . . . . . . . . . . . . . . . 10’ to 120’ standard (custom sizes available)
Scale Capacity . . . . . . . . . . . . . . . . 60-150 tons
Concentrated Load Capacity . . . . . . 90k or 100k
Deck construction . . . . . . . . . . . . . .Welded steel deck plate (Model 8565);
Product assembly . . . . . . . . . . . . . . Modular (1 to 6 modules)
Approvals . . . . . . . . . . . . . . . . . . . .
NTEP CC# 22-087 / MC# AM-6004
Load Cell
Capacity . . . . . . . . . . . . . . . . . . . . 66,000 lbs or 100,000 lbs
Type . . . . . . . . . . . . . . . . . . . . . . . Rocker column
Construction . . . . . . . . . . . . . . . . . Stainless steel
Rating . . . . . . . . . . . . . . . . . . . . . . IP69K (NEMA 6P)
Sealing . . . . . . . . . . . . . . . . . . . . . Hermetic
Resistance . . . . . . . . . . . . . . . . . . 1,000 ohms
Overload capacity . . . . . . . . . . . . 300%
Cable protection . . . . . . . . . . . . . . Armour Guard
Options . . . . . . . . . . . . . . . . . . . . . Intalogix lightning/surge protection
Approvals . . . . . . . . . . . . . . . . . . . NTEP CC# 92-098 / Factory Mutual
Falcon 8565XD EXTRA HEAVY DUTY Steel Deck Truck Scale, 120k CLC
1 module – 2 sections (27’)
92936 8565XD Series, 27’ x 10’ – 75 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12,800 lbs
92944 8565XD Series, 27’ x 11’ – 75 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14,100 lbs
92952 8565XD Series, 27’ x 12’ – 75 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15,400 lbs
92960 8565XD Series, 27’ x 14’ – 75 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18,000 lbs
1 module – 2 sections (30’)
92937 8565XD Series, 30’ x 10’ – 75 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14,200 lbs
92945 8565XD Series, 30’ x 11’ – 75 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15,600 lbs
92953 8565XD Series, 30’ x 12’ – 75 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17,100 lbs
92961 8565XD Series, 30’ x 14’ – 75 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19,900 lbs
1 module – 2 sections (35’)
92938 8565XD Series, 35’ x 10’ – 75 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16,500 lbs
92946 8565XD Series, 35’ x 11’ – 75 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18,200 lbs
92954 8565XD Series, 35’ x 12’ – 75 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19,800 lbs
92962 8565XD Series, 35’ x 14’ – 75 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23,100 lbs
2 modules – 3 sections (60’)
92939 8565XD Series, 60’ x 10’ – 125 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28,400 lbs
92947 8565XD Series, 60’ x 11’ – 125 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31,200 lbs
92955 8565XD Series, 60’ x 12’ – 125 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34,200 lbs
92963 8565XD Series, 60’ x 14’ – 125 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39,800 lbs
2 modules – 3 sections (70’)
92940 8565XD Series, 70’ x 10’ – 125 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33,000 lbs
92948 8565XD Series, 70’ x 11’ – 125 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36,400 lbs
92956 8565XD Series, 70’ x 12’ – 125 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39,600 lbs
92964 8565XD Series, 70’ x 14’ – 125 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46,200 lbs
3 modules – 4 sections (80’)
92941 8565XD Series, 80’ x 10’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38,400 lbs
92949 8565XD Series, 80’ x 11’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42,300 lbs
92957 8565XD Series, 80’ x 12’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46,200 lbs
92965 8565XD Series, 80’ x 14’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54,000 lbs
3 modules – 4 sections (90’)
92942 8565XD Series, 90’ x 10’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42,600 lbs
92950 8565XD Series, 90’ x 11’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46,800 lbs
92958 8565XD Series, 90’ x 12’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51,300 lbs
92966 8565XD Series, 90’ x 14’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59,700 lbs
3 modules – 4 sections (105’)
92943 8565XD Series, 105’ x 10’ – 150 to capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49,500 lbs
92951 8565XD Series, 105’ x 11’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54,600 lbs
92959 8565XD Series, 105’ x 12’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59,400 lbs
92967 8565XD Series, 105’ x 14’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69,300 lbs
Falcon 8565HD HEAVY DUTY Steel Deck Truck Scale, 100k CLC
1 module – 2 sections (10’)
92784 8565HD Series, 10’ x 10’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4,874 lbs
92799 8565HD Series, 10’ x 11’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5,422 lbs
92814 8565HD Series, 10’ x 12’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5,789 lbs
1 module – 2 sections (15’)
92785 8565HD Series, 15’ x 10’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6,365 lbs
92800 8565HD Series, 15’ x 11’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6,932 lbs
92815 8565HD Series, 15’ x 12’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7,799 lbs
1 module – 2 sections (20’)
92786 8565HD Series, 20’ x 10’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7,913 lbs
92801 8565HD Series, 20’ x 11’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8,887 lbs
92816 8565HD Series, 20’ x 12’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9,600 lbs
1 module – 2 sections (23’)
92787 8565HD Series, 23’ x 10’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9,206 lbs
92802 8565HD Series, 23’ x 11’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10,201 lbs
92817 8565HD Series, 23’ x 12’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11,089 lbs
2 modules – 3 sections (30’)
92788 8565HD Series, 30’ x 10’ – 90 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12,959 lbs
92803 8565HD Series, 30’ x 11’ – 90 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13,864 lbs
92818 8565HD Series, 30’ x 12’ – 90 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15,600 lbs
2 modules – 3 sections (40’)
92789 8565HD Series, 40’ x 10’ – 90 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15,826 lbs
92804 8565HD Series, 40’ x 11’ – 90 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17,775 lbs
92819 8565HD Series, 40’ x 12’ – 90 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19,200 lbs
2 modules – 3 sections (47’)
92790 8565HD Series, 47’ x 10’ – 90 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18,413 lbs
92805 8565HD Series, 47’ x 11’ – 90 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20,433 lbs
92820 8565HD Series, 47’ x 12’ – 90 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22,987 lbs
3 modules – 4 sections (60’)
92791 8565HD Series, 60’ x 10’ – 120 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23,738 lbs
92806 8565HD Series, 60’ x 11’ – 120 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26,666 lbs
92821 8565HD Series, 60’ x 12’ – 120 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28,800 lbs
3 modules – 4 sections (70’)
92792 8565HD Series, 70’ x 10’ – 120 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27,767 lbs
92807 8565HD Series, 70’ x 11’ – 120 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30,603 lbs
92822 8565HD Series, 70’ x 12’ – 120 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33,267 lbs
4 modules – 5 sections (80’)
92793 8565HD Series, 80’ x 10’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31,651 lbs
92808 8565HD Series, 80’ x 11’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35,547 lbs
92823 8565HD Series, 80’ x 12’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38,401 lbs
4 modules – 5 sections (90’)
92794 8565HD Series, 90’ x 10’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35,532 lbs
92809 8565HD Series, 90’ x 11’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39,489 lbs
92824 8565HD Series, 90’ x 12’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44,356 lbs
5 modules – 6 sections (100’)
92795 8565HD Series, 100’ x 10’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39,564 lbs
92810 8565HD Series, 100’ x 11’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44,433 lbs
92825 8565HD Series, 100’ x 12’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47,720 lbs
5 modules – 6 sections (110’)
92796 8565HD Series, 110’ x 10’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43,278 lbs
92811 8565HD Series, 110’ x 11’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48,682 lbs
92826 8565HD Series, 110’ x 12’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54,012 lbs
5 modules – 6 sections (117’)
92797 8565HD Series, 117’ x 10’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46,259 lbs
92812 8565HD Series, 117’ x 11’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50,984 lbs
92827 8565HD Series, 117’ x 12’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55,422 lbs
6 modules – 7 sections (120’)
92798 8565HD Series, 120’ x 10’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48,101 lbs
92813 8565HD Series, 120’ x 11’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53,724 lbs
92828 8565HD Series, 120’ x 12’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58,291 lbs
Falcon 8565 Steel Deck Truck Scale, 90k CLC
1 module – 2 sections (10’)
92754 8565 Series, 10’ x 10’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3,948 lbs
92769 8565 Series, 10’ x 11’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4,358 lbs
1 module – 2 sections (15’)
92755 8565 Series, 15’ x 10’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5,166 lbs
92770 8565 Series, 15’ x 11’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5,691 lbs
1 module – 2 sections (20’)
92756 8565 Series, 20’ x 10’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7,164 lbs
92771 8565 Series, 20’ x 11’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7,872 lbs
1 module – 2 sections (23’)
92757 8565 Series, 23’ x 10’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8,027 lbs
92772 8565 Series, 23’ x 11’ – 60 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8,759 lbs
2 modules – 3 sections (30’)
92758 8565 Series, 30’ x 10’ – 90 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9,975 lbs
92773 8565 Series, 30’ x 11’ – 90 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10,972 lbs
2 modules – 3 sections (40’)
92759 8565 Series, 40’ x 10’ – 90 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13,678 lbs
92774 8565 Series, 40’ x 11’ – 90 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15,058 lbs
2 modules – 3 sections (47’)
92760 8565 Series, 47’ x 10’ – 90 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16,128 lbs
92775 8565 Series, 47’ x 11’ – 90 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17,548 lbs
3 modules – 4 sections (60’)
92761 8565 Series, 60’ x 10’ – 120 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20,307 lbs
92776 8565 Series, 60’ x 11’ – 120 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22,356 lbs
3 modules – 4 sections (70’)
92762 8565 Series, 70’ x 10’ – 120 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23,919 lbs
92777 8565 Series, 70’ x 11’ – 120 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26,154 lbs
4 modules – 5 sections (80’)
92763 8565 Series, 80’ x 10’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27,102 lbs
92778 8565 Series, 80’ x 11’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29,811 lbs
4 modules – 5 sections (90’)
92764 8565 Series, 90’ x 10’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30,283 lbs
92779 8565 Series, 90’ x 11’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33,361 lbs
5 modules – 6 sections (100’)
92765 8565 Series, 100’ x 10’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33,285 lbs
92780 8565 Series, 100’ x 11’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36,614 lbs
5 modules – 6 sections (110’)
92766 8565 Series, 110’ x 10’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37,320 lbs
92781 8565 Series, 110 x 11’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41,099 lbs
5 modules – 6 sections (117’)
92767 8565 Series, 117’ x 10’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39,849 lbs
92782 8565 Series, 117’ x 11’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43,572 lbs
6 modules – 7 sections (120’)
92768 8565 Series, 120’ x 10’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39,964 lbs
92783 8565 Series, 120’ x 11’ – 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44,329 lbs
Falcon 8565 PV Portable Truck Scale - 90k CLC – Steel Deck
92829 8565 PV, 60’ x 10’, 120 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27,767 lbs
92830 8565 PV, 70’ x 10’, 120 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30,419 lbs
92831 8565 PV, 80’ x 10’, 150 ton capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34,102 lbs
Options
Instrumentation, printers, rub rails, traffic light kits, deck runners, remote displays, legal-for-trade dump through, drop plates, blow down plates, custom software, rub rail cutout, 8555 and 8555HD concrete deck versions
