Digi DC-788 Industrial Counting Scale

DIGI DC-788 digital counting scales have earned a reputation for delivering quality and innovation to industrial businesses through the United States. This unique line of counting equipment is designed to provide solutions for a wide range of applications, from basic portable scales for straight weighing to high-powered counting systems.

The DIGI DC-788 exceeds all expectations of a counting scale — rugged and reliable -- at a price point that can’t be beat! With a capacity of up to 100 pounds, and an optional rechargeable battery that provides up to 24 hours of continuous usage, this durable counting scale offers tremendous power and virtually unlimited flexibility. Its bright red LCD display can be seen from any angle and is highly visible in low light areas.

As a general rule when determining sample size of fairly uniform pieces, the larger the sample size the greater the total sample weight, therefore, the better the counting accuracy. Selecting the smallest capacity scale that can obtain the highest counting resolution should be considered, but should not sacrifice the capacity required for the heaviest container of parts. There is a direct relationship between piece-to-piece weight variation (non-uniformity) and counting accuracy.

The DC-788 is an affordable counting scale that offers practical solutions for a full range of counting applications. Its counting resolution of 1/1,000,000 gives you maximum counting precision and accuracy. Its high-visibility red LCD display enables operators to easily see weights and quantities.

With the ability to store an item code, part number, part name, lot number, tare weight, unit weight, inventory quantity and setpoint value for 100 of your pieces, parts, or items, the DC-788 is a self-contained inventory system. The RS-232 output allows you to connect to a printer or PC, while the remote scale channel lets you add another weighing platform.

When portability is required, choose the battery operation option of the DC788 for over 24 hours of continuous use in mobile workstations, outdoor applications, and rental fleets. Its splash-proof housing make the DC-788 rugged enough to operate reliably in many environments and withstand transport from one area of the plant to another or from one business to the next.

If accuracy and ease-of-use are important, the DC-788 is a must-have. With its RS-232 interface, you can easily attach a scanner or printer for all your labeling applications. And only the DC-788 enables you to customize your output by allowing specific spec codes to be disabled. With the DC-788’s increased capacity and power, you can now do much more economically!

PART # ..... MODEL ..... CAPACITY ..... RESOLUTION .... PLATTER ........ SHIP WT

88928 ..........DC-788 ......2.0 lb ...........0.0002 lb .................7" x 10" ..........15 lb (7 kg)

88929 ..........DC-788 ......10 lb ...........0.001 lb ....................9" x 12" ..........15 lb (7 kg)

88930 ..........DC-788 ......20 lb ............0.002 lb ...................9" x 12" ..........15 lb (7 kg)

88931 ..........DC-788 ......50 lb ............0.005 lb ...................9" x 12" ..........15 lb (7 kg)

88932 ..........DC-788 ......100 lb ...........0.01 lb ....................9" x 12" ..........15 lb (7 kg)

Options Available
88933    Rechargeable battery–lead acid type
73386    Anti-static sample tray
32375    14-Pin load cell connector, Amphenol (remote base, non-DIGI)
35319    14-Pin load cell connector with 20 ft cable
91685    Additional operating and service manual
37528    9-Pin printer cable to DT4, G500
72440    9-Pin printer cable to Epson TM-U220/TM-U295 SP512
66535    9-Pin cable to PC, null modem cable
91214    AC adapter
132424  DT-4, 4 in Direct Thermal
132425  G500, 4 in Thermal Transfer
65617    Label 2.25 x 4.5 in with perf, Direct Thermal

Replacement Parts

DC-788

89994 Keysheet, 16 keys............................... ........... 43002085100101.............
89997 Keysheet, 8 keys................................. ........... 43002005100301...............
89999 Keyboard............................................ ........... 41012690901100...............
90152 Main board.......................................... ........... 43002090900100.............
90153 Load cell, 2 lb...................................... ........... 43002066200400.............
90154 Load cell, 10 lb.................................... ........... 43001060200100.............
90155 Load cell, 20 lb.................................... ........... 43002060200200.............
90156 Load cell, 50 lb.................................... ........... 41001060200300.............
90159 Load cell, 100 lb.................................. ........... 43002060200500.............
90188 Cover top............................................ ........... 43002002800600...............
90160 Platter support.................................... ........... 41012608800102...............
90171 Platter cover 10 lb-100 lb..................... ........... 41012650200900.............
65956 Platter cover 2 lb.................................. ........... 40303200040320.............
108518 AC adapter 110-240 US plug............. .......................................................
92549 Board, pre-amp A/D........................... ............. 4300209091300.............
96797 Display lens......................................... ........... 43002050100201...............
97368 Sealing screws.................................... ........... 41004601300200.................
97369 White washers.................................... ........... 41012602900101.................
98398 Display board...................................... ........... 43002090900200.............
151443 Leveling foot........................................ .........................................................
73588 Rubber support................................... .......................................................
163482 DC Input Jack..................................... .......................................................
